memberOf SAML2 attribute

Synchronize groups via SAML2

Flexopus implemented the standard SAML2 Single Sign On protocol, which is supposed to work with any identity providers that follows the SAML2 standard. Often it's not only required to set up a Single Sign On configuration for the login, but it's also necessary to exchange group memberships. This way, the user can access the right Flexopus resources after the first log in.

Some identity providers provide an API to synchronize groups in real time. Such integrations are in place at Google via the Google Management API and at Microsoft via the SCIM API.

Google Groups Sync
Why synchronizing Google Groups? The integration is recommended for customers using Google Workspace internally as Identity Provider (IdP). User groups on the organizational level are often already defined and managed within Google. You can synchronize these groups to Flexopus using the Google Directory API with domain-wide delegation. The synchronized groups
Azure Active Directory SCIM API
Introduction You can integrate with Microsoft Azure Active Directory (Azure AD) via federated authentication or using SCIM (System for Cross-domain Identity Management), allowing users to log in to Flexopus using their existing Azure AD credentials. Flexopus can be linked to an instance of Microsoft Azure Active Directory (Azure AD) via

Other identity providers, such as Microsoft AD FS or KeyCloak, unfortunately lack the capability to synchronize user groups via the SCIM API. As a workaround, we enable user groups to be exchanged as an additional attribute during the SAML2 authorization process, specifically through the attribute called memberOf.

IMPORTANT: Verify if your identity provider supports the SCIM v2 interface. If available, it’s recommended to synchronize groups using SCIM instead of using the SAML2 memberOf attribute.

Instruction Manual

We assume that you already successfully configured the SAML2 integration between your identity provider and Fleoxpus, if not, please visit:

SAML2 for a custom provider
Which Identity Providers are supported for SAML2? Flexopus implemented the standard SAML2 Single Sign On protocol, which suppose to work with any Identity Providers that follows the SAML2 standard. Flexopus acts as a Service Provider. Therefore, you can try to connect your Identity Provider, even if we do not provide

STEP 1 - Configure Flexopus

Navigate in Flexopus to Dashboard > Settings > Authentication as an administrator. Click on the preconfigured SAML2 provider and locate the synchronize groups setting, which is turned off by default. You can select from the following options:

  1. Off - No group synchronization.
  2. Array - Enables group synchronization using an array format.
  3. memberOf - Synchronizes groups based on the memberOf attribute.

Activate groups syncronization

You can see the following options listed:


AD FS OPTION
Known IdPs require this option: Microsoft AD FS
The AD FS option will send the groups in a so called LDAP Array. The first CN will be the name of the group:

["CN=Group1,CN=...,DC=...,OU=Flexopus,OU=Org", "CN=Group2,CN=...,DC=...,OU=Flexopus,OU=Org"]

ARRAY OPTION
Known IdPs require this option: KeyCloak
The ARRAY option will send the groups in a classic array:

["Group1", "Group2"]

COMMA SEPARATE OPTION
This option will send the groups in a comma separated list:

Group1,Group2

STEP 2 - Configure your IdP

You need to configure which attributes shall be synchronized between your identity provider and Flexopus. Connect the according attribute in your identity provider with the memberOf attribute:

'memberOf' => [
    'memberOf'
]

STEP 3 - Reduce session time

With SAML2, groups are sent to Flexopus only when the user initiates a login. To ensure daily group synchronization, consider setting a lower session time, such as 24 hours. This setting prompts users to log in at least once a day, enabling consistent group updates.

To configure this, navigate in Flexopus to Dashboard > Settings > Data Privacy Settings and adjust the Session lifetime. Since users typically have an active session with your identity provider, the login will usually be a simple one-click process.


Important notes


Limited request size

Note: The memberOf attribute is part of a request, for logical reasons you can not send an unlimited number of groups through this array. If the limit is reached, no groups will be sent. The limit is depending on the sending and the receiving side. For example, Microsoft limits it: Learn more here. You should not send more than 100 groups via this attribute.


Identifying groups

In Flexopus, groups are identified by unique names. If Flexopus receives a group with a name that already exists as an internal group, it converts that group into an external group. When Flexopus receives a group with a new name, it automatically creates it as an external group.


Internal vs. external groups

After login, any groups received through memberOf are handled as external groups and will be attached to the user. Any other external groups not included in the received list are detached from the user, while internal groups remain unchanged.

Learn more about the groups here:

User groups
Introduction Here you can see a list of action you can do with user groups to use and manage them as an administrator: How to manage the user groups? * Manage groups manually * Manage groups via the SCIM API * Manage groups via SAML2 (memberOf) * Import users and groups (CSV and XLSX)

Trouble Shooting and FAQ

Can I only add one external group to the user and keep others?

External groups are managed via the memberOf attribute in this configuration. The single source of through is what we receive with this attribute. Make sure you send all external groups that suppose to be associated with the user.

Can I configure the memberOf synchronization with multiple identity providers at the same time?

No. This is not supported. We can support the groups synchronization only for one identity provider.

Can I use SCIM and the memberOf attributes parallel?

No. This is not supported. We can support the groups synchronization only for one identity provider.
